waterproof pigtail

High reliability 2 4 6 8 10 12 0.9 2 3mm FC waterproof pigtail

FC/PC
Delivery
FOB
Quantity:
Contact Now
  • Place of Origin:CN;GUA
  • Brand Name:Skylynn
  • Model Number:FC/PC
  • Product name:pigtail
  • Application:FTTH FTTB FTTX Network
  • connector type:PC/UPC/APC
  • Certification:CE RoHS
  • Wavelength:1310/1550nm
  • Type:FC/SC/ST/LC
  • Material:PVC
  • fiber type:simplex and Duplex
  • Connector:SC LC FC ST MU
  • Warranty:2 Years



 High reliability 2 4 6 8 10 12 0.9 2 3mm FC waterproof pigtail



Product Description



Features:

(1) Ceramic Ferrule;

(2) High return loss;

(3) Low insertion loss;

(4) Good repeatability and and exchangeability;

(5) Excellent Polished and 100% tested;

(6) Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard.





Applications:



(1) Local Area Network (LAN)

(2) Data communication network

(3) Telecommunication optical transmission network

(4) Optical access network(OAN)

(5) Active device termination

(6) Fiber optics data transmission(FODT)

(7) Test Equipment

(8) CATV



Specification

Mode

SM

MM

Polish

UPC

APC

PC

Insertion Loss

Typical ≤0.2dB

Maximum ≤0.3dB

≤0.25dB

Return Loss

≥50dB

≥65dB

≥35dB

Interchangeability

≤0.2dB

Repeatability

≤0.1dB

Durability

≤0.2dB (1000 times mating)

Tensile Strengh

>10kg

Temperature

≤0.2dB (-40+85 sustain 100 hours)

Humidity

≤0.2dB  (+25+65 93 R.H.100 hours)









Certifications



Packaging







company information

Shenzhen Skylynn Communication Limimted is an industry leader in providing GCS (Generic Cabling System) such as fiber optic products and LAN Cabling system products, engineering expertise and integrated services to the data communications and telecommunication networks industry since 2007. We design, manufacture and install such products that communications providers need to provide high-speed voice, video and data services to their customers.

Our extensive experience in both design and application crosses all markets, from Telco, Broadband and Wireless, to Electric Utility, OEM, Enterprise and Private Networks.
Nearly 10 years’ experiences in massive production of fiber optical assemblies ensure the reliable stabilities of its high quality and excellent performances of its products. It obtains the good reputations all these years from customers around the earth for its short lead-time, fast delivery, and timely after-services.









FAQ
